Development of a Voice-Controlled Wheelchair for Physically Impaired Individuals
Main Article Content
Keywords
Voice-controlled wheelchair, voice recognition, quadriplegia, assistive technology, assistive devices
Abstract
Background and Objective: Traditional manual wheelchairs provide mobility to individuals with physical impairments but are poorly suited for individuals with a combination of physical and cognitive or perceptual impairments. Manual wheelchairs are more physically demanding than powered wheelchairs; however, powered wheelchairs require cognitive and physical skills that not all individuals possess. The general objective of this study is to develop a voice-controlled wheelchair that allows a disabled person to move around independently using a voice-recognition application that is interfaced with motors. The study will be beneficial for quadriplegic individuals who are paralyzed in both arms and both legs.
Material and Methods: This study aims to modify a standard wheelchair controlled by voice commands where the EasyVR 3 Voice Recognition Module, ultrasonic sensors, microcontroller, and 12V wiper motor were integrated. Based on the signal given by the motor driving circuit, the controller switches the motor accordingly. The added safety feature is the ultrasonic sensor that senses obstacles with a fall detection system and sends a signal to the microcontroller to stop the chair.
Results: Through testing and evaluation, the device’s functionality was proven to meet the desired objectives, and the limitations of the device were concluded. The motors and sensors were also found to be 100% functional. The average speed of the wheelchair is 0.2 m/s, and it can move with the user weighing up to 80 kg. The wheelchair lifts at an angle of up to 10˚. The overall acceptability of the unit, analyzed using statistical parameters like mean method and standard deviation analysis, gives a 4.53 average, 4.53 on usability, 4.07 on correctness, 4.37 on control, 4.50 on reliability, 4.33 on safety, and 4.8 on comfort, which means the unit meets the objectives.
Conclusion: Based on the evaluation results, the project met the given objectives. The system was able to move following the voice command given. The device also proved its functionality, responsiveness, usability, correctness, control, reliability, safety, and comfortability. While the current study demonstrates the feasibility of voice-controlled wheelchairs, future research should focus on improving the accuracy and robustness of voice recognition systems and the incorporation of sensory feedback mechanisms, such as haptic feedback or auditory cues.
Downloads
References
Kumar D, Malhotra R and Sharma SR. Design and Construction of a Smart Wheelchair. Procedia Computer Science 2020;172:302–307. doi: 10.1016/j.procs.2020.05.048.
Machol K et al. Hearing Loss In Individuals With Osteogenesis Imperfecta In North America: Results From A Multicenter Study. Am J Med Genet 2020;182(4):697–704. doi: 10.1002/ajmg.a.61464.
Sadowska M, Sarecka-Hujar B, and I. Kopyta. Cerebral Palsy: Current Opinions on Definition, Epidemiology, Risk Factors, Classification and Treatment Options. Neuropsychiatr Dis Treat 2020;16:1505–1518. doi: https://doi.org/10.2147/NDT.S235165.
Quadri SA, et al. Recent update on basic mechanisms of spinal cord injury. Neurosurg Rev 2020;(43)2:425–441. 2020, doi: 10.1007/s10143-018-1008-3.
Tan CEK, and Chao YX. Historical Perspective: Models of Parkinson’s Disease. Internat J Molec Sci 2020;21:7. doi: 10.3390/ijms21072464.
Deguchi M, Tsuji S, Katsura D, et al. Current Overview of Osteogenesis Imperfecta. Medicina 2021;57(5). doi: 10.3390/medicina57050464.
Meyyazhagan A and Orlacchio A. Hereditary Spastic Paraplegia: An Update. Internat J Molec Sci 2022;23(3). doi: 10.3390/ijms23031697.
Anjum F and Seetha M. Voice-Activated System for Disabled People Using IoT. in Proceedings of the 2nd International Conference on Cognitive and Intelligent Computing, A. Kumar, G. Ghinea, and S. Merugu, Eds., Singapore: Springer Nature Singapore. 2023:219–226.
Arboleda ER, Paulite YVP and Carandang NJC. Smart Wheelchair with Dual Control using Touchpad and Android Mobile Device. Indonesian J Electric Engineer Informat 2018;6(1). doi: http://dx.doi.org/10.52549/ijeei.v6i1.342.
Elsokah M, Mejber AD, Zerek AR, et al. Next Generation of Smart Wheelchair with Speech Command. In The 7th International Conference on Engineering & MIS 2021, in ICEMIS’21. New York, NY, USA: Association for Computing Machinery, 2021. doi: 10.1145/3492547.3492758.
Berndt AE. Sampling Methods. J Hum Lact 2020;36(2):224–226. doi: 10.1177/0890334420906850.
Dutta PP, et al. Design and Development of Voice Controllable Wheelchair. In 2020 8th International Conference on Reliability, Infocom Technologies and Optimization (Trends and Future Directions) (ICRITO), Jun. 2020, pp. 1004–1008. doi: 10.1109/ICRITO48877.2020.9197765.
Umchid S, Limhaprasert P, Chumsoongnern S, et al. Voice Controlled Automatic Wheelchair. In 2018 11th Biomedical Engineering International Conference (BMEiCON), Nov. 2018, pp. 1–5. doi: 10.1109/BMEiCON.2018.8609955.
Bisognin A, et al. Ball Grid Array Module With Integrated Shaped Lens for 5G Backhaul/Fronthaul Communications in F-Band. IEEE Transactions on Antennas and Propagation vol. 65, no. 12, pp. 6380–6394, Dec. 2017, doi: 10.1109/TAP.2017.2755439.
Raiyan Z, Nawaz MS, Adnan AK, and Imam MH. Design of an arduino based voice-controlled automated wheelchair. In 2017 IEEE Region 10 Humanitarian Technology Conference (R10-HTC), Dec. 2017, pp. 267–270. doi: 10.1109/R10-HTC.2017.8288954.
